1.33x Front Anamorphic Adapter

Best Affordable 2X Anamorphic Solution

Laowa is introducing a 1.33X Front Anamorphic Adapter as a standalone perk or as an add-on! The adapter is a must-get for the anamorphic shooters. Get it now and mount on our Nanomorph for a 2X anamorphic experience.

*Delivery time is around 3 to 4 weeks.

Description

Minimal Loss of Aperture Stops & Image Quality

One of the challenges of using an anamorphic adapter is that it can result in a loss of aperture stops and image quality. This means that the image may not be as bright or sharp as it would be without the adapter.

©Brandon Li – 80mm T2.4 1.5X (Silver)

To provide our filmmakers with the maximum performance of the adapter, we have created a special design to ensure the loss of aperture stops and image quality are minimal, allowing filmmakers to achieve the desired anamorphic look.

©Cam Mackey – 65mm T2.4 1.5X (Blue)

Button-controlled Rotational Mechanism

Enabling the rotation of the lens element internally to ensure correct image compression and horizontal flare alignment.

Compatible with Full-Frame Lenses

©Cam Mackey – 65mm T2.4 1.5X (Blue)

The 1.33X Anamorphic Adapter is compatible with our Ranger Cine Zoom lenses and can be mounted seamlessly, working as an anamorphic zoom lens while providing functionality across a focal range of 48mm to 100mm.

List of Compatible Nanomorph Focal Lengths (With Suitable Step-up Ring):

Nanomorph 27mm

Nanomorph 35mm*

Nanomorph 50mm*

Nanomorph 65mm

Nanomorph 80mm

Micro Four Thirds

Super 35

Super 35/Full-Frame

*Installation of 77mm step-up rings is not required for the usage of PL/EF versions.

Sample Footage

Review

Specification (1.33X Front Anamorphic Adapter)

Name	Laowa 1.33X Front Anamorphic Adapter
Squeeze Ratio	1.33X
Lens Structure	5 elements in 5 groups
Focus Throw	200°
Focus Indicator	Foot & Meter (Dual Scale)

Min. Focusing Distance	2’4” / 73cm
In-focus Driving Mode	Manual (MF)
Front Diameter	Ø90mm
Filter Thread Diameter	Ø86mm
Max. Diameter	Ø96mm
Rear Diameter	Ø77mm (55mm /62mm /77mm step-up rings are included)
Dimensions	Ø3.78”2.76” / Ø96mm70mm
Weight	About 1.83lb/830g
Flare Colour	Amber/Blue/Silver
